Pemancar AM 1000 Watt

Lebih Lengkap Mengenai Pemancar AM 1000 Watt

Barang Baru


AM TRANSMITTER 520 - 1800 KHz 1000 W PEP



The GiantAM1000W Digital PLL exciter covers partially the AM Broadcast Band available in ranges of 530 ~ 1000 KHz and 1000 ~ 1800 KHz with step size of 1 KHz. It can deliver 1000 Watt P.E.P. at 50 Ohm Load ( 160 Watt CW @ 100% modulation )
The LCD screen of GiantAM1000W displays operating Frequency , Lock state , RF Power Forward and Reflected , Heatsink temperature , Audio Modulation Level % and also displays Alarm reasons of any kind of malfunction.
The GiantAM1000W has protections from high VSWR , Over output Power , Over Temperature , Unlocked Frequency , Over modulation Power Supply malfunction . When an Alarm gets activated , the controller restarts the Exciter operation three times. If this procedure fails to solve the malfunction , the exciter goes to STBY mode. The GiantAM1000W needs
100 ~ 240VAC to operate and its weight is 16Kg max.

SPECIFICATIONS :
Frequency Band : 0,53~1,0 - 1,0 ~ 1,8 MHz
Output Resistance : 50 Ohm
Output RF Power : 0 ~ 1000 Watt P.E.P. , Continuous 800W PEP
Carrier : 0 ~ 160 Watt C.W.
Frequency Step size : 1,00 KHz
Harmonics : < -50 db
Spurius : < -65 db
Modulation Type : AM - DSB
Supply Voltage : 100-240 Volt AC
Supply Consumption : < 2000 Watt
AF Input Resistance : 10 KOhm
AF Input level : > 300 mV p - p
AF responce : 10 Hz ~ 10 KHz -3 db
Weight : < 25Kg
Dimensions : UR 1 Metal Box
Warranty : 2 Years
