Greenstone 3CX-1500A7

Lebih Lengkap Mengenai Greenstone 3CX-1500A7

Barang Baru
Ready Stock

Greenstone Tube , Pabrik memberikan garansi 2 tahun.
Greenstone tube langsung di import dari USA

80% broadcast di USA, telah menggunakan Greenstone


YU-158/8877/3CX1500A7

Electrical specifications for the 3CX1500A7 / 8877 Vacuum Tube:

Filament Oxide coated
Voltage .45 Volts
Current 10.5 Amps
Amplification factor 200
Plate Dissipation 1500 Watts
Grid Dissipation 25 Watts
Maximum frequency for full rating CW 250 MHz
Capacitance Grounded Cathode connection:
Input
Output
Feedback

Mechanical specifications for the 3CX1500A7 / 8877 Vacuum Tube:

Cooling Forced air
Base 7 pin
Length 4.02 in.
Diameter 3.38 in.
Weight 1.6 lbs.
